Gazelle ChamonixT10 HMS
Gazelle Chamonix T10 HMS
From £2,849Maximum range 135 km

Comfortable e-bike for long recreational trips thanks to derailleur gears

Chamonix T10 HMS

Chamonix T10 HMS

The Chamonix T10 HMS has everything: style, performance, comfort — down to the smallest detail. You can cycle anywhere with ease, thanks in part to the 10 gears.

Maximum range
135 km
Frame shape
High-step, Low-step
Gears
10
Brake Rear
Disc brake with hydraulic control
From £2,849

Discover the Chamonix

Discover the Chamonix

Intelligent battery integrated into the down tube

Shimano's high-performance, lithium-ion batteries have an intelligent battery-management system that provides the maximum possible range. The battery is nicely integrated into the down tube, which improves road holding. Its compact size makes it easy to slide it in and out of the e-bike. You can choose the battery capacity that suits you: 504 Wh or 630 Wh. The battery is reliably secured with a lock on your frame and is easily removed using your bike key. Convenient, as you can charge the battery either on or off the bike.
Intelligent battery integrated into the down tube Gazelle Chamonix T10 HMS E-bike low-step brewster grey
Shimano STEPS E6100 (60 Nm) Gazelle Chamonix T10 HMS E-bike low-step brewster grey

Smooth up-hill performance with Shimano's powerful motor

The Shimano E6100 motor is a very versatile motor that you can use in any terrain. With 60 Nm torque you can easily handle both flat and hilly terrains. What's more, at 2.88 kg this motor is very light.

Battery and range

Platinum

  • Maximum range135 km
  • Watt-hours504 Wh
  • Capacity13,8 Ah
  • Eco range135 km
  • Standard range85 km
  • High range65 km
  • Additional price (excluding disposal fee)Price: This is included in the MSRP

Diamond

  • Maximum range160 km
  • Watt-hours630 Wh
  • Capacity17,5 Ah
  • Eco range160 km
  • Standard range105 km
  • High range75 km
  • Additional price (excluding disposal fee)£170
Platinum
Diamond
Maximum range
135 km
160 km
Watt-hours
504 Wh
630 Wh
Capacity
13,8 Ah
17,5 Ah
Eco range
135 km
160 km
Standard range
85 km
105 km
High range
65 km
75 km
Additional price (excluding disposal fee)
Price: This is included in the MSRP
£170
Your handlebars can be adjusted in seconds Gazelle Chamonix T10 HMS E-bike low-step brewster grey

Your handlebars can be adjusted in seconds

The Chamonix T10 HMS features the Gazelle Switch handlebar stem, so you can adjust your handlebars to the perfect height in an instant. Therefore, you can cycle in any riding position you want. In addition, the braking, shifting and lighting cables are neatly tucked away inside the frame. That means well-protected cables and a sleeker look.

Powerful and controlled braking

If you're cycling downhill or in busy city traffic, then you'll want to be able to brake safely without thinking about it. Hydraulic disc brakes offer braking power and precision, so you can slow down in a controlled manner at any time — even when it's raining.
Powerful and controlled braking Gazelle Chamonix T10 HMS E-bike low-step brewster grey
A chain without a weak link Gazelle Chamonix T10 HMS E-bike low-step brewster grey

A chain without a weak link

With the proven Deore derailleur gearing system, you choose how and when to shift gears, tailored to the electric pedal assistance. Especially on hills, you will benefit from the large gear range (11 to 42 teeth at the rear). The extra-reinforced e-bike chain changes gears smoothly thanks to the Shimano gear shifters. Because everything is coordinated and in tune, you can shift intuitively and smoothly with the motor drive. Ideal when you are cycling uphill and downhill.

Powerful assistance

The Shimano mid-drive motor provides powerful assistance on any terrain. Its 60-Nm output helps you quickly get up the mountain or accelerate rapidly at traffic lights. With your choice of a 504-Wh or 630-Wh battery, you can go on long journeys.
Powerful assistance Gazelle Chamonix T10 HMS E-bike low-step brewster grey
Logo Gazelle

"Nice stable bike, comfortable due to the wide tyres, easy to handle. Strong motor and great disc brakes."

Gazelle's customer
We make 300,000 bikes a year, assembled by hand.
Our bicycles are consistently checked for quality, from paint job to performance.

Specifications

Gear system description
10-speed Shimano Deore

Engine model
Shimano STEPS E6100 (60 Nm)

Model
Chamonix

Colorname
Brewster grey

Fork suspension type
Internal to headset

Model
Chamonix

Luxury rating
****

Weight in kg.
23.1 kgs

Colorname
Brewster grey

Segment
Electric bicycles

Sitting position
Upright, Active


Frame

Frame shape
High-step, Low-step
Size
49, 53, 57, 61, 65
Frame description
Sporty and stable aluminium frame with 70.5⁰ head tube angle and 71.5⁰ saddle tube angle. Cables are nicely concealed through the unique cable integration system. Battery integrated in the frame for large capacity (630 Wh)
Frame material
Aluminium
Cabels integrated
Yes

Fork

Fork material
Aluminium
Fork suspension type
Internal to headset
Travel of suspension fork
40 mm

Wheels

Wheelsize
28"
Rims
Mach1 650, Double-walled aluminium for extra strong and efficient cycling performance
Spoke description
Stainless steel, extra strong

Tires

Tires
Schwalbe Big Apple
Tire color
Black
Tires puncture resistant
Yes

Number of gears

Gear system description
10-speed Shimano Deore
Gear type
Derailleur
Gears
10
Rear derailleur
Shimano Deore
Front chainwheel
38
Rear chainwheel
11-42

Brakes

Brake Front
Disc brake with hydraulic control
Brake Rear
Disc brake with hydraulic control
Disc brake rotor size front
180 mm
Disc brake rotor size rear
160 mm
Brake system description front
Alhonga HT474, 2 piston
Brake system description rear
Alhonga HT474, 2 piston

Handlebar

Handlebar description
Aluminium, slightly curved model
Adjustable stem
Yes
Grip type
Herrmans Primo
Grips
Plastic handlebar grips with ergonomic form for a better distribution of pressure on the hands

Saddle

Saddle
BBB Diamond
Seatpost suspension
Yes
Seatpost description
Sprung
Seatpost diameter
27,2 mm

Front light

Light front description
LED headlamp, on/off switching via display
Front light type
Trelock Veo 50

Engine

Ebike system short description
Shimano STEPS
Engine location
Mid-drive motor
Max Speed (km/h)
25 km/h
Max speed (mph)
15,5 mph
Torque
60
Engine model
Shimano STEPS E6100 (60 Nm)
Ebike sensors
Pedal force sensor, rotation sensor, speed sensor

Battery

Battery type
Li-ion
Battery position
Integrated into frame
Battery replaceable
Yes
Ebike charger description
2 Ah

Display

Amount of support levels
3
Walk assist
Yes
Display Model
Shimano Steps LCD center
Display detachable
Yes

Garantie

Warranty frame
10 years’ warranty
Warranty fork
5 years’ warranty
Warranty paint
5 years’ warranty
Warranty other parts
2 years’ warranty
Warranty battery
2 years’ warranty
Warranty motor
2 years’ warranty
Warranty diplay
2 years’ warranty

Lock

Lock description
Ring lock
Lock safety level
ART ** certified
Lock Type
Axa Block XXL

Other

Chaincase description
Aluminum
Kickstand type
Drop-down rear stand
Kickstand
Ursus Mooi
Chaincase type
Chain guard

Carrier

Rear carrier description
Aluminum MIK HD system carrier
Carrier MIK system
Yes
Max. load rear carrier (kg.)
25 kg
