Gazelle UltimateT10 HMB
Gazelle Ultimate T10 HMB
From £3,499Maximum range 155 km

Sporty trekking e-bike with large gear range thanks to derailleur

Ultimate T10 HMB

Ultimate T10 HMB

The Ultimate T10 HMB is perfect for getting out in the great outdoors. Enjoy hills or flat terrain for as long as you want. This sporty e-trekking bike has a high-quality finish.

Maximum range
155 km
Frame shape
High-Step, Low-Step
Number of gears
10
From £3,499

Craftsmanship

With over 130 years of expertise, we know precisely what we're doing. Creating bicycles that you can rely on. What begins with a design comes together in our factory. Where we work everyday to create the perfect Gazelle for you.

Discover the Ultimate

Efficient, integrated power source

Bosch's lithium-ion batteries are among the most advanced on the market. Their intelligent battery management system guarantees a long life, while the efficient energy control optimises your bike's range. With the integrated 500- or 625-Wh battery, you'll always have enough range. The battery is secured in the frame with a lock. You can easily remove it from the bike using the bike key, so you can recharge the battery anywhere.
Efficient, integrated power source Gazelle Ultimate T10 HMB E-bike low-step thunder grey
Performance Line Gazelle Ultimate T10 HMB E-bike low-step thunder grey

The wind is always at your back with a Bosch Performance Line motor

The Bosch Performance Line gives you everything your cyclist's heart desires. Smooth and powerful assistance that will never let you down. With 75 Nm torque you can handle any terrain. Highly recommended for the demanding cyclist.

Battery and range

Diamant

  • Watt-hours625 Wh
  • Capacity17,4 Ah
  • Battery charging time with 2A-
  • Battery charging time with 4A4 h 54 m
  • Battery positionintergrated in the frame
  • Battery brandBosch
  • Battery modelIntube
  • Battery voltage36V
  • Eco155 km
  • Tour95 km
  • Auto70 km
  • Turbo65 km

Platina

  • Watt-hours500 Wh
  • Capacity13,4 Ah
  • Battery charging time with 2A7 h 30 m
  • Battery charging time with 4A4 h 30 m
  • Battery positionintergrated in the frame
  • Battery brandBosch
  • Battery modelIntube
  • Battery voltage36V
  • Eco130 km
  • Tour75 km
  • Auto60 km
  • Turbo50 km
Diamant
Platina
Watt-hours
625 Wh
500 Wh
Capacity
17,4 Ah
13,4 Ah
Battery charging time with 2A
-
7 h 30 m
Battery charging time with 4A
4 h 54 m
4 h 30 m
Battery position
intergrated in the frame
intergrated in the frame
Battery brand
Bosch
Bosch
Battery model
Intube
Intube
Battery voltage
36V
36V
Eco
155 km
130 km
Tour
95 km
75 km
Auto
70 km
60 km
Turbo
65 km
50 km
Logo Gazelle

"This bike offers a good balance between comfort, design and quality. It's always a pleasure to head out on a bike ride."

Gazelle's customer
We make 300,000 bikes a year, assembled by hand.
Our bicycles are consistently checked for quality, from paint job to performance.

Specifications

Color
Frozen white gloss, thunder grey gloss

Fork suspension
Telescope, spiral spring

Ebike System Model
Performance Line

Motor
Bosch Smart System Performance Line

Bike weight description
Excl. battery

Weight (kg)
24.3 kgs

Weight
24.3 excl. battery

Color
Frozen white gloss, thunder grey gloss

Bike Max. Total Weight (kg)
130

Sitting Position
Active


Frame

Frame description
Stable aluminium frame with 70,5° headset angle and 71,5° saddle tube angle for sporty cycling characteristics. Battery, motor and cables harmoniously integrated into the frame. High-quality finish with attention to detail.
Frame material
Aluminum
Cockpit Cable Integration
Yes
Frame shape
High-Step, Low-Step
Frame Size CM
46, 49, 53, 57, 61, 65

Fork

Fork
SR Suntour NVX30
Fork description
Suntour NVX30
Fork Material
Aluminum
Fork suspension
Telescope, spiral spring
Fork lockout
Yes

Wheels

Front wheel
38
Rear wheel
Front rim
Dutch 19 Dutch 19, double-walled aluminium for extra strong and efficient cycling performance
Rear rim
Dutch 19 Dutch 19, double-walled aluminium for extra strong and efficient cycling performance
Front hub
Shimano
Rear hub
Shimano Deore
WheelSize Front
28"

Tires

Wheels Tire Front Etrto
50-622
Front tyre
Schwalbe Energizer Plus
Rear tyre
Schwalbe Energizer Plus
Wheels Tire Front Description
Schwalbe Energizer Plus

Number of gears

Brand shifters
Shimano
Front chainwheel
38
Cassette Range
11-42
Gear Type
Derailleur
Number of gears
10

Drivetrain

Rear derailleur
Shimano Deore
Drivetrain
Chain
Crankset Model
Delta
Crankset description
Miranda Delta

Brakes

Front Brake Type
Hydraulic disc brake
Brake sytem code
S10
Front Brake Brand
Magura
Primary Rear Brake Model
MT-C4
Front brake
Magura MT-C4, 180 mm
Rear brake
Magura MT-C4, 160 mm
Rear Brake Lever
MaguraCT4

Handlebar

Handlebar
Ergon GP1-L ergonomic, plastic handlebar grips with ergonomic form for a better distribution of pressure on the hands
Stem adjustable
Yes
Cockpit Handlebar Grip Brand
Ergon

Saddle

Saddle
Selle Royal Essenza Plus

Front light

Front light
Herrmans MR8
Front Light Energy Source
Battery
Front Light Lux
60

Rear light

Rear Light Energy Source
Battery
Rear light
Spanninga Commuter Glow

Engine

Ebike System Model
Performance Line
Motor
Bosch Smart System Performance Line
Ebike System Brand
Bosch Smart System
Ebike Engine Position
Mid
Ebike Max Speed kmh
25
Ebike Engine Max Torque (Nm)
75

Battery

Charger
Bosch
Ebike Battery Charger Description
4 Ah
Ebike Battery Position
Intergrated in the frame

Display

Display
Bosch Kiox 300
Ebike Display Removeable
Yes
Ebike Walk Assist
Yes
Ebike Display Type
LCDc

Garantie

Frame warranty
10 year's warranty
Fork warranty
5 year's warranty
Paint warranty
5 year's warranty
Other parts warranty
2 year's warranty
Battery warranty
2 year's warranty
Motor warranty
2 year's warranty
Display warranty
2 year's warranty

Lock

Lock
Axa
Lock brand
Axa
ART classification
ART**

Other

Kickstand
Ursus Mooi

Carrier

Rear carrier description
Aluminum MIK HD system carrier
Carrier MIK Profile
Yes
Rear carrier max load (kg)
27
Rear carrier
Yes
Made by hand, for a superb result every single time.
