Gazelle AvignonC5 HMB
From £0Maximum range 155 km
Ultimate comfort and powerful performance
Avignon C5 HMB
The epitome of comfort and power: Avignon C5 HMB. Ride comfortably upright and experience the powerful performance.
Maximum range
155 km
Frame shape
Low-Step
Number of gears
5
From £0
Craftsmanship
With over 130 years of expertise, we know precisely what we're doing. Creating bicycles that you can rely on. What begins with a design comes together in our factory. Where we work everyday to create the perfect Gazelle for you.
Discover the Avignon
)
Efficient, integrated power source
Bosch's lithium-ion batteries are among the most advanced on the market. Their intelligent battery management system guarantees a long life, while the efficient energy control optimises your bike's range. With the integrated, 500 or 625-Wh battery, you'll always have enough range. The battery is secured in the frame with a lock. You can easily remove it from the bike with the bike key. Convenient, as you can charge the battery either on or off the bike.
Discover new places with Bosch's quiet, yet powerful motor
The Bosch Performance Line gives you everything your cyclist's heart desires. Smooth and powerful assistance that will never let you down. With 65 Nm torque you can handle any terrain. Highly recommended for the demanding cyclist.
Battery and range
- Watt-hours500 Wh
- Capacity13,4 Ah
- Ebike battery charging time with 2A charger7 h 30 m
- Ebike battery charging time with 4A charger4 h 30 m
- Battery positionintergrated in the frame
- Battery brandBosch
- Battery modelIntube
- Voltage36V
- Eco130 km
- Tour75 km
- Auto60 km
- Turbo50 km
Accu powertube 625WH Bosch vertikaal Bes4
- Watt-hours625 Wh
- Capacity17,4 Ah
- Ebike battery charging time with 2A charger-
- Ebike battery charging time with 4A charger4 h 54 m
- Battery positionintergrated in the frame
- Battery brandBosch
- Battery modelIntube
- Voltage36V
- Eco155 km
- Tour95 km
- Auto70 km
- Turbo65 km
Accu powertube 625WH Bosch vertikaal Bes4
Watt-hours
500 Wh
625 Wh
Capacity
13,4 Ah
17,4 Ah
Ebike battery charging time with 2A charger
7 h 30 m
-
Ebike battery charging time with 4A charger
4 h 30 m
4 h 54 m
Battery position
intergrated in the frame
intergrated in the frame
Battery brand
Bosch
Bosch
Battery model
Intube
Intube
Voltage
36V
36V
Eco
130 km
155 km
Tour
75 km
95 km
Auto
60 km
70 km
Turbo
50 km
65 km
Protected against theft
The Avignon C5 HMB is a bike with Gazelle Connect. It's a smart e-bike with theft protection. A module connected to the Internet is built into the e-bike. This module ensures that the bike is always traceable using GPS. This is also clearly marked on the bike frame, so thieves will think twice before trying to make off with it. If the bike starts moving, you will receive a notification via the Gazelle App.
Always in control
The Avignon C5 HMB has extra-wide tyres for good road holding and increased comfort. The Magura disc brakes guarantee excellent braking power, which is easy to control in all conditions. With the large brake levers, that goes without saying. This means you are always in control.
Integrated LED lighting
The daytime running lights on the Avignon C5 HMB do their job, day and night. The powerful 70 lux front light is integrated into the mudguard. And with the rear light in the carrier, you are easily visible not only from behind but also from the side.
No need to worry about maintenance
Maintenance is not an issue with the Avignon C5 HMB because it features the Shimano Nexus 5. This gear hub is specially designed for e-bikes and is therefore highly resistant to the tensile force of the powerful, mid-drive motor. You can rack up the kilometres without giving it a single thought.
"All in all a very attractive and sturdy bike. Not the cheapest, but you pay for the quality you get."
Gazelle's customer
)
Specifications
- Color
- Orion blue matte
- Fork suspension
- Mono Integrated
- System Model
- Performance Line
- Bike weight description
- Excl. battery
- Weight (kg)
- 28.4 kgs
- Weight
- 28.4 excl. battery
- Color
- Orion blue matte
- Front Light Integrated
- Yes
- Bike Max. Total Weight (kg)
- 130
- Sitting Position
- Upright
- Frame description
- Stable aluminium frame with 68.5° head tube angle and 69.5° saddle tube angle. Cables are nicely concealed through the unique cable integration system. Battery integrated in the frame for large capacity (625 Wh)
- Frame material
- Aluminum
- Cockpit Cable Integration
- Yes
- Frame shape
- Low-Step
- Frame Size CM
- 49, 53, 57, 61
- Fork Material
- Aluminum
- Fork suspension
- Mono Integrated
Frame
Fork
- Front wheel
- 46, Gates
- Rear wheel
- 34, Gates
- Front rim
- Ryde ZAC 25, double-walled aluminium for extra strong and efficient cycling performance
- Rear rim
- Ryde ZAC 25, double-walled aluminium for extra strong and efficient cycling performance
- Front hub
- Shimano
- Rear hub
- Shimano Nexus 5
- WheelSize Front
- 28"
- Wheels Tire Front Etrto
- 55-622
- Front tyre
- Scalato Mondano
- Rear tyre
- Scalato Mondano
Wheels
Tires
- Brand shifters
- Shimano
- Front chainwheel
- 46
- Gear Type
- Hub
- Number of gears
- 5
- Drivetrain
- Belt
- Front Brake Type
- Hydraulic disc brake
- Brake sytem code
- S5
- Front Brake Brand
- Tektro
- Primary Rear Brake Model
- HD-R3020
- Front brake
- Tektro HD-T3020, 180 mm
- Rear brake
- Tektro HD-R3020, 160 mm
- Rear Brake Lever
- TektroHDT3020
Number of gears
Drivetrain
Brakes
- Handlebar
- Gazelle Aero leather, luxury leather handlebar grips for a sophisticated feel and extra comfort
- Stem adjustable
- Yes
- Cockpit Handlebar Grip Brand
- Gazelle
- Saddle
- Selle Royal Essenza Plus gel
Handlebar
Saddle
- Front light
- Gazelle Fendervision
- Front Light Energy Source
- Battery
- Front Light Lux
- 70
- Rear Light Energy Source
- Battery
- Rear light
- Spanninga Commuter Glow
Front light
Rear light
- System Model
- Performance Line
- Ebike System Brand
- Bosch Smart System
- Ebike Engine Position
- Mid
- Ebike Max Speed kmh
- 25
- Engine Max Torque (Nm)
- 75
- Charger
- Bosch Standard charger,
- Ebike Battery Charger Description
- 4 Ah
- Battery Position
- Intergrated in the frame
- Display
- Bosch Intuvia 100
- Display Removeable
- Yes
- Ebike Walk Assist
- Yes
- Display Type
- LCD
Engine
Battery
Display
- Frame warranty
- 10 year's warranty
- Fork warranty
- 5 year's warranty
- Paint warranty
- 5 year's warranty
- Other parts warranty
- 2 year's warranty
- Battery warranty
- 2 year's warranty
- Motor warranty
- 2 year's warranty
- Display warranty
- 2 year's warranty
Garantie
- Lock
- Abus
- Lock brand
- Abus
- ART classification
- ART**
- Chain guard
- Chain guard
- Kickstand
- Ursus Mooi
- Chaincase type
- Chain guard
- Coat protector
- Yes
- Rear carrier description
- Aluminum MIK HD system carrier
- Carrier MIK Profile
- Yes
- Rear carrier max load (kg)
- 27
- Rear carrier
- Yes
Lock
Other
Carrier
Made by hand, for a superb result every single time.
Awards
Our Avignon C8 HMB surprised our judges
Take our word for it. Or take a ride.
We've done our best to capture the Gazelle experience in words, but there is nothing like the real thing. So why not book a test ride at one of our Gazelle bike stores?
)
