Specifications
Battery
Charger
Shimano, 2A
Battery Position
on the frame
Display
Display model
Shimano SC-EN600
Display Removable
false
Support levels
3
Support modes
Eco, Normal, High
Ebike Walk Assist
true
Motor
Maximum Speed
15 mph
Engine Max Torque (Nm)
50
Motor
EP5
Ebike Engine Position
Mid
Ebike System Brand
Shimano
Battery and range
| 630 Wh | 418 Wh | 504 Wh | |
|---|---|---|---|
| Capacity | 17,5 Ah | 11,6 Ah | 14 Ah |
| Battery brand | Shimano | Shimano | Shimano |
| Battery charging time with 2A | 10 h 12 m | 6 h 30 m | 7 h 30 m |
| Battery charging time with 4A | 5 h 30 m | 4 h | 4 h 30 m |
| Battery model | Ontube | Ontube | Ontube |
| Eco | 112 mi | 75 mi | 94 mi |
| Normal | 72 mi | 44 mi | 56 mi |
| High | 53 mi | 32 mi | 41 mi |
| Voltage | 36V | 36V | 36V |
630 Wh
Capacity
17,5 Ah
Battery brand
Shimano
Battery charging time with 2A
10 h 12 m
Battery charging time with 4A
5 h 30 m
Battery model
Ontube
Eco
112 mi
Normal
72 mi
High
53 mi
Voltage
36V
418 Wh
Capacity
11,6 Ah
Battery brand
Shimano
Battery charging time with 2A
6 h 30 m
Battery charging time with 4A
4 h
Battery model
Ontube
Eco
75 mi
Normal
44 mi
High
32 mi
Voltage
36V
504 Wh
Capacity
14 Ah
Battery brand
Shimano
Battery charging time with 2A
7 h 30 m
Battery charging time with 4A
4 h 30 m
Battery model
Ontube
Eco
94 mi
Normal
56 mi
High
41 mi
Voltage
36V
Fork
Fork Material
steel
Fork suspension
Rigid
Frame
Frame description
Aluminium frame with a unique geometry with a low step-through which allows you as cyclist to always get your feet on the ground, so you don’t have to get off when you stop. Mid-mounted motor and low positioned battery provide great stability.
Frame material
aluminum
Frame shape
Low-Step
Frame Size CM
XS(46)
Weight
54.7 lbs excl. battery
Color
anthracite grey gloss
Model
Easyflow
Segment
Electric bicycles, City bikes
Sitting Position
Upright
Handlebar
Handlebar description
aluminium, comfort curved model
Grips
Ergon GC10, plastic handlebar grips with ergonomic form for a better distribution of pressure on the hands
Stem adjustable
true
Saddle
Saddle
Selle Royal Gipsy
Seatpost suspension
false
Front light
Front Light Energy Source
battery
Front light
Busch & Müller Upp
Rear light
Rear Light Energy Source
battery
Rear light
Spanninga Solo
Carrier
Front carrier
false
Rear carrier
true
Rear carrier description
aluminum MIK system carrier
Carrier MIK Profile
true
Lock
Lock
Axa
Lock description
ring lock with an option for a plug-in cable to attach your bike to a fixed object for extra protection against theft
ART classification
ART**
Other
Kickstand
Ursus Mooi
Kickstand type
side stand
Battery warranty
2 year's warranty
Display warranty
2 year's warranty
Fork warranty
10 year's warranty
Frame warranty
10 year's warranty
Motor warranty
2 year's warranty
Paint warranty
5 year's warranty
Other parts warranty
2 year's warranty
Brakes
Front brake
Tektro HD-R280
Front brake disc diameter
160 mm
Front brake lever
Tektro
Front brake piston number
2
Front Brake Type
hydraulic disc brake
Rear brake
Tektro HD-R280
Rear brake disc diameter
160 mm
Rear Brake Lever
Tektro
Rear brake piston number
2
Rear brake type
hydraulic disc brake/
Drivetrain
Drivetrain
KMC X8
Drivetrain
chain
Front sprocket
38
Rear sprocket
18
Gears
Gear
Shimano Nexus 8
Gear Type
Hub
Number of gears
8
Tires
Wheels Tire Front Etrto
55-406
Wheels Tire Rear Etrto
55-406
Front tyre
Schwalbe Big Ben Plus
Rear tyre
Schwalbe Big Ben Plus
Wheels
Front hub
Shimano
Front rim
Ryde Andra 40, double-walled aluminium for extra strong and efficient cycling performance
WheelSize Front
24"
Rear hub
Shimano Nexus 8 Di2
Rear rim
Ryde Andra 40, double-walled aluminium for extra strong and efficient cycling performance
WheelSize Rear
24"
