Royal Dutch Gazelle
Esprit

Specifications

Model
Esprit
Color
legion blue matte, moss green matte, space anthracite matte
Segment
Electric bicycles, City bikes
Sitting Position
Upright
Weight
51.1 lbs excl. battery
Motor
Ebike System Brand
Shimano
Motor
EP5
Engine Max Torque (Nm)
50
Ebike Engine Position
Mid
Maximum Speed
15 mph
Battery
Battery Position
on the frame
Charger
Shimano EC-E6002, 2A
Display
Support levels
3
Support modes
Eco, Normal, High
Ebike Walk Assist
Yes
Display model
Shimano SC-EN500
Display Type
LCD
Display Removable
No
Wheels
WheelSize Front
28"
WheelSize Rear
28"
Front rim
Ryde Dutch, double-walled aluminium for extra strong and efficient cycling performance
Rear rim
Ryde Dutch, double-walled aluminium for extra strong and efficient cycling performance
Front hub
Shimano
Rear hub
Shimano Nexus 7
Tires
Front tyre
Schwalbe Fat Frank
Rear tyre
Schwalbe Fat Frank
Wheels Tire Front Etrto
50-622
Wheels Tire Rear Etrto
50-622
Gears
Number of gears
7
Gear Type
Hub
Gear
Shimano Nexus 7
Brakes
Front Brake Type
hydraulic disc brake
Rear brake type
hydraulic disc brake/
Front brake
Shimano BR-MT200
Rear brake
Shimano BR-MT200
Front brake piston number
2
Rear brake piston number
2
Front brake disc diameter
160 mm
Rear brake disc diameter
160 mm
Front brake lever
Shimano BL-MT200
Rear Brake Lever
Shimano BL-MT200
Drivetrain
Drivetrain
chain
Front sprocket
38
Rear sprocket
18
Frame
Frame shape
Low-Step, High-Step
Frame Size CM
S(49), L(59), M(54), XL(64), XS(46)
Frame description
Stable, lightweight oversized aluminium frame with 70.5° headset angle and 71.5° saddle tube angle gives positive steering characteristics. Low-step frame with spacious step-through, double tube.
Frame material
aluminum
Fork
Fork Material
steel
Fork suspension
Rigid
Handlebar
Handlebar description
aluminum, slightly curved
Stem adjustable
Yes
Grips
plastic wear-resistant handlebar grips for a firm grasp
Saddle
Saddle
Selle Royal
Seatpost suspension
No
Front light
Front light
AXA Ecoline
Front Light Energy Source
battery
Rear light
Rear light
AXA Blueline
Rear Light Energy Source
battery
Frame warranty
10 year's warranty
Fork warranty
10 year's warranty
Paint warranty
5 year's warranty
Battery warranty
2 year's warranty
Motor warranty
2 year's warranty
Display warranty
2 year's warranty
Other parts warranty
2 year's warranty
Lock
Lock
Axa
Lock description
ring lock with an option for a plug-in cable to attach your bike to a fixed object for extra protection against theft
ART classification
ART**
Other
Chain guard
Chain case
Kickstand
Ursus Mooi
Kickstand type
drop-down rear stand
Carrier
Rear carrier
Yes
Carrier MIK Profile
Yes
Rear carrier description
aluminum MIK HD system carrier
Front carrier
No
418 Wh
Capacity
11,6 Ah
Battery charging time with 2A
6 h 30 m
Battery charging time with 4A
4 h
Battery brand
Shimano
Battery model
Ontube
Voltage
36V
Eco
75 mi
Normal
44 mi
High
32 mi
504 Wh
Capacity
14 Ah
Battery charging time with 2A
7 h 30 m
Battery charging time with 4A
4 h 30 m
Battery brand
Shimano
Battery model
Ontube
Voltage
36V
Eco
94 mi
Normal
56 mi
High
41 mi
