This is my first Gazelle electric bike, and my second electric bike. I wanted lower maintenance than my Trek so I went with Gates belt drive and Enviolo shifting. Much smoother ride compared to having chain and derailleur. I also updated my bike to have front fork suspension. I live in hilly area of northern Virginia and ride on gravel and asphalt paths with a lot of root cracks. Front suspension has been amazing to take pressure off my arthritic hands. Superior ride compared to my Trek with upgraded components. Big plus is being able to adjust handlebars while out on a ride without tools. Really helps my posture my hands. Well done Gazelle!
Sarah BindbeutelMay 2, 2026
This is a well made...
This is a well made bike; it is quite expensive because of the features like the nice screen/electronics and shock absorbers. The bike is heavy with a large battery. I purchase the bike because the battery was supposed to have a long range. However the battery runs down much more quickly than they advertise. I have a relatively flat commute to work, about 8 km (5 miles) total a day. I go from 100% charge to ~20% in 4 days (32 km) of riding using a combination of Eco, Tour, and Auto, with only occasional Turbo. I am not heavy (<50 kilos) so the bike should not be having to work too hard! I have had to purchase another charger to keep at work in case I run the battery down too low and can't get home (as I said the bike with very heavy and hard to ride without power).
Whendee SilverDecember 22, 2025
Certifications
Intertek ETL Listed
Specifications
Battery
Charger
Bosch Compact Charger, 2A
Battery Position
integrated in the frame
Display
Display
Bosch Kiox 300
Display Removable
true
Display Type
LCD colour
Support Levels
4
Support Values
Eco, Tour, Auto, Turbo
Ebike Walk Assist
true
Motor
Ebike Max Speed
20 mph
Engine Max Torque (Nm)
75
Motor
Performance Line
Ebike Engine Position
Mid
Ebike System Brand
Bosch Smart System
Battery and Range
540 Wh
Capacity
15 Ah
Battery Brand
Bosch
Ebike Battery Charging Time with 2A Charger
7 h 42 m
Battery Model
Intube
Eco
94 mi
Tour
56 mi
Auto
44 mi
Turbo
38 mi
Voltage
36V
540 Wh
Capacity
15 Ah
Battery Brand
Bosch
Ebike Battery Charging Time with 2A Charger
7 h 42 m
Battery Model
Intube
Eco
94 mi
Tour
56 mi
Auto
44 mi
Turbo
38 mi
Voltage
36V
Fork
Fork Lockout
false
Fork Material
aluminum
Fork Suspension
Telescope, spiral spring
Fork Travel
50 mm
Frame
Frame Description
Stable, lightweight hydro-formed aluminum frame with 68.5° headset angle and 69.5° seat tube angle for relaxed and comfortable riding. This is a low-step and spacious frame, single tube and lovely integrated cables
Frame Material
aluminum
Frame hape
Low-Step
Frame Size CM
L(57), M(53), S(46)
Weight (lbs)
60.8 lbs excl. battery
Color
caramel khaki gloss, metallic orange matte
Model
Arroyo
Segment
Electric bicycles, City bikes
Sitting Position
Upright
Handlebar
Handlebar Description
aluminum, comfort curved model
Cockpit Handlebar Grip Brand
Gazelle Aero Leather, luxury leather handlebar grips for a sophisticated feel and extra comfort
Stem Adjustable
true
Saddle
Saddle
Selle Royal Lena Gel
Seatpost Suspension
true
Front Light
Front Light Energy Source
battery
Front Light
Gazelle Fendervision
Rear Light
Rear Light Energy Source
battery
Rear Light
Spanninga Pimento
Carrier
Front Carrier
false
Rear Carrier
true
Rear Carrier Description
aluminum MIK HD system carrier
Carrier MIK Profile
true
Lock
Lock
Axa
Lock Description
ring lock with an option for a plug-in cable to attach your bike to a fixed object for extra protection against theft
ART Classification
ART**
Other
Kickstand
Ursus Mooi
Kickstand Type
drop-down rear stand
Battery Warranty
2 year's warranty
Display Warranty
2 year's warranty
Fork Warranty
5 year's warranty
Frame Warranty
10 year's warranty
Motor Warranty
2 year's warranty
Paint Warranty
5 year's warranty
Other Parts Warranty
2 year's warranty
Brakes
Front Brake
Tektro HD-T280
Front Brake
180 mm
Front Brake Lever
Tektro HD-T280
Front Brake Piston Number
2
Front Brake Type
hydraulic disc brake
Rear Brake
Tektro HD-T280
Rear Brake
160 mm
Rear Brake Lever
Tektro HD-T280
Rear Brake Piston Number
2
Rear Brake Type
hydraulic disc brake/
Drivetrain
Drivetrain
Gates CDC
Drivetrain
belt
Front Sprocket
46, Gates CDC
Rear Sprocket
24, Gates CDC
Gears
Rear derailleur
Enviolo Trekking Manual
Gear Type
Hub
Number of gears
Stepless
Tires
Wheels Tire Front ETRTO
50-622
ETRTO Tire Rear
50-622
Front Tire
Schwalbe Energizer Active Plus
Rear Tire
Schwalbe Energizer Active Plus
Wheels
Front hub
Shimano
Front rim
Ryde ZAC 421, Double-walled aluminum for extra strong and efficient cycling performance
Front Wheel Size
28"
Rear Hub
Enviolo Trekking Manual
Rear Rim
Ryde ZAC 421, Double-walled aluminum for extra strong and efficient cycling performance
)
