This is my first Gazelle electric bike, and my second electric bike. I wanted lower maintenance than my Trek so I went with Gates belt drive and Enviolo shifting. Much smoother ride compared to having chain and derailleur. I also updated my bike to have front fork suspension. I live in hilly area of northern Virginia and ride on gravel and asphalt paths with a lot of root cracks. Front suspension has been amazing to take pressure off my arthritic hands. Superior ride compared to my Trek with upgraded components. Big plus is being able to adjust handlebars while out on a ride without tools. Really helps my posture my hands. Well done Gazelle!
Sarah Bindbeutel2 mei 2026
This is a well made...
This is a well made bike; it is quite expensive because of the features like the nice screen/electronics and shock absorbers. The bike is heavy with a large battery. I purchase the bike because the battery was supposed to have a long range. However the battery runs down much more quickly than they advertise. I have a relatively flat commute to work, about 8 km (5 miles) total a day. I go from 100% charge to ~20% in 4 days (32 km) of riding using a combination of Eco, Tour, and Auto, with only occasional Turbo. I am not heavy (<50 kilos) so the bike should not be having to work too hard! I have had to purchase another charger to keep at work in case I run the battery down too low and can't get home (as I said the bike with very heavy and hard to ride without power).
Whendee Silver22 december 2025
Certifications
Intertek ETL Listed
Specifications
Accu
Acculader
Bosch Compact Charger, 2A
Accu locatie
integrated in the frame
Display
Display model
Bosch Kiox 300
Display afneembaar
Ja
Display type
LCD colour
Aantal ondersteuningsstanden
4
Ondersteuningsstanden
Eco, Tour, Auto, Turbo
Loopassistentie
Ja
Motor
Maximum Speed
20 mph
Koppel
75
Motor
Performance Line
Motor locatie
Mid
E-bike systeem
Bosch Smart System
Batterij en bereik
540 Wh
540 Wh
Amperes
15 Ah
15 Ah
Merk
Bosch
Bosch
Accu laadtijd 2A lader
7 h 42 m
7 h 42 m
Accu model
Intube
Intube
Eco
80 mi
80 mi
Tour
50 mi
50 mi
Auto
35 mi
35 mi
Turbo
30 mi
30 mi
Voltage
36V
36V
540 Wh
Amperes
15 Ah
Merk
Bosch
Accu laadtijd 2A lader
7 h 42 m
Accu model
Intube
Eco
80 mi
Tour
50 mi
Auto
35 mi
Turbo
30 mi
Voltage
36V
540 Wh
Amperes
15 Ah
Merk
Bosch
Accu laadtijd 2A lader
7 h 42 m
Accu model
Intube
Eco
80 mi
Tour
50 mi
Auto
35 mi
Turbo
30 mi
Voltage
36V
Voorvork
Lock-out voorvork
Nee
Materiaal voorvork
aluminum
Vering voorvork
Telescope, spiral spring
Veerweg voorvork
50 mm
Frame
Frame omschrijving
Stable, lightweight hydro-formed aluminum frame with 68.5° headset angle and 69.5° seat tube angle for relaxed and comfortable riding. This is a low-step and spacious frame, single tube and lovely integrated cables
Materiaal frame
aluminum
Frame model
Low-Step
Framemaat
S(46), M(53), L(57)
Gewicht
60.8 lbs excl. battery
Kleur
metallic orange matte, caramel khaki gloss
Model
Arroyo
Segment
Electric bicycles, City bikes
Zithouding
Upright
Stuur
Stuur omschrijving
aluminum, comfort curved model
Handvatten
Gazelle Aero Leather, luxury leather handlebar grips for a sophisticated feel and extra comfort
Stuurpen verstelbaar
Ja
Zadel
Zadel
Selle Royal Lena Gel
Verende zadelpen
Ja
Koplamp
Voeding koplamp
battery
Koplamp
Gazelle Fendervision
Achterlicht
Voeding achterlicht
battery
Achterlicht
Spanninga Pimento
Drager
Voordrager
Nee
Bagagedrager
Ja
Omschrijving achterdrager
aluminum MIK HD system carrier
MIK-systeem drager
Ja
Slot
Slot
Axa
Slot omschrijving
ring lock with an option for a plug-in cable to attach your bike to a fixed object for extra protection against theft
Slot veiligheidsniveau
ART**
Overig
Standaard
Ursus Mooi
Type standaard
drop-down rear stand
Garantie accu
2 year's warranty
Garantie display
2 year's warranty
Garantie voorvork
5 year's warranty
Garantie frame
10 year's warranty
Garantie motor
2 year's warranty
Garantie lak
5 year's warranty
Garantie onderdelen
2 year's warranty
Remmen
Rem voor
Tektro HD-T280
Diameter remschijf voor
180 mm
Remhendel voor
Tektro HD-T280
Aantal zuigers rem voor
2
Remsysteem voor
hydraulic disc brake
Rem achter
Tektro HD-T280
Diameter remschijf achter
160 mm
Remhendel achter
Tektro HD-T280
Aantal zuigers rem achter
2
Remsysteem achter
hydraulic disc brake/
Aandrijving
Ketting/Riem
Gates CDC
Aandrijving
belt
Tandwiel voor
46, Gates CDC
Tandwiel achter
24, Gates CDC
Versnelling
Versnelling
Enviolo Trekking Manual
Type versnelling
Hub
Aantal versnellingen
Stepless
Banden
Bandenmaat ETRTO voor
50-622
Bandenmaat ETRTO achter
50-622
Band voor
Schwalbe Energizer Active Plus
Band achter
Schwalbe Energizer Active Plus
Wielen
Naaf voor
Shimano
Velg voor
Ryde ZAC 421, Double-walled aluminum for extra strong and efficient cycling performance
Wielmaat
28"
Naaf achter
Enviolo Trekking Manual
Velg achter
Ryde ZAC 421, Double-walled aluminum for extra strong and efficient cycling performance
)
