What is the best frame size for me?

Gazelle eBike frame sizes are based on the height of the bicycle in centimeters. Selecting the correct frame size depends on a number of factors: your height, inseam, and reach, the sitting position, and your individual riding style preference. Starting with your height, we can make size recommendations to help you narrow down the choices and discover your perfect fit. A properly sized bike will ensure you enjoy the ride farther and longer.

We are happy to help you find the right fit.

Calculate your frame size

Enter your height in the field below to get our recommendations. We may give you multiple sizes if you are between sizes. Need help? Visit one of our dealers.

VISIT A DEALER

Need personal advice?

You can easily have your frame size calculated at one of our Gazelle dealers. Our dealers are well-versed in our sizes and their corresponding height ranges, as well as taking other measurements to help dial in the perfect fit for you. You can also test ride multiple sizes and bike models to ensure you are making the right choice.

Find a store nearby

Bike frame size overview

The ideal bike frame size is easily calculated based on your height. Frame sizes are in centimeters, measuring the length of the vertical tube in the frame where the saddle is attached. The bike frame size chart below lists the height ranges for each size. However, this is an initial recommendation, and other factors may influence your frame size choice. If you are between sizes, we recommend test riding both sizes.

Height Frame size Frame size
4'10" -  5'6" 45 S
4'10" -  5'6" 46 S
5'6" - 5'10" 50 M
5'6" - 5'10" 53 M
5'10" - 6'3" 55 L
5'10" - 6'3" 57 L



FAQ's about frame sizes

Why do you recommend multiple bike frame sizes?

We have different frames available in different sizes. For example, the Gazelle Medeo is available in 45, 50, and 55 cm sizes, while the Gazelle Ultimate is available in 46, 53, and 57 cm sizes. A bike frame size at Gazelle is always shown in centimeters and is the distance between the top of the seat tube and the center of the bottom bracket.

Because we use different frames for our bikes, you may receive multiple frame sizes as advice. Especially if you have an average body height, almost every bike available is in a suitable frame size.

In addition, your ideal frame size depends on a number of factors: type of bike (e.g. ebike or city bike), your inseam, sitting position, and whether you want a sprung saddle. Personal preference is also important. We always advise to go test drive so that you can experience the differences in frame sizes for yourself.

Can I measure my frame size myself?

You can calculate the frame size of your bike yourself by measuring your inseam. But how do you do this?

  • Grab a tape measure
  • Take off your shoes and socks and place your feet 20 cm apart
  • Measure (or have measured) the distance from the crotch to the ground
  • Multiply the distance by 0.68: this is your ideal frame size
  • Do you have a bike with a suspension seat post? Then calculate: frame size minus 4

Where is the frame size of my Gazelle bike?

The frame size of your Gazelle bike can be found on the sticker near your bottom bracket, above the lock, or on the tube under the saddle.

What is the best frame size for me?

Gazelle Ultimate

To best determine your frame size, please visit one of our Gazelle stores. Our bikes are tested and approved for riders up to 130Kg or about 285 pounds. Rear racks are tested and approved for up to 25Kg or 55 pounds of cargo, unless noted differently.

Height (rider) Size
4'10" - 5'6" S (46)
5'6"- 5'10" M (53)
5'10" - 6'3" L (57)

Download Geometry

What is the best frame size for me?

Gazelle Medeo

To best determine your frame size, please visit one of our Gazelle stores. Our bikes are tested and approved for riders up to 130Kg or about 285 pounds. Rear racks are tested and approved up to 55 pounds of cargo, unless noted differently.

Height (rider) Size
4'10" - 5'6" S (45)
5'6"- 5'10" M (50)
5'10" - 6'3" L (55)

Download Geometry

What is the best frame size for me?

Gazelle Arroyo Elite

To best determine your frame size, please visit one of our Gazelle stores. Our bikes are tested and approved for riders up to 130Kg or about 285 pounds. Rear racks are tested and approved up to 55 pounds of cargo, unless noted differently.

Height (rider) Size
4'10" - 5'6" S (46)
5'6"- 5'10" M (53)
5'10" - 6'3" L (57)

Download Geometry

What is the best frame size for me?

Gazelle Avignon

To best determine your frame size, please visit one of our Gazelle stores. Our bikes are tested and approved for riders up to 130Kg or about 285 pounds. Rear racks are tested and approved up to 55 pounds of cargo, unless noted differently.

Height (rider) Size
4'10" - 5'6" S (46)
5'6"- 5'10" M (53)
5'10" - 6'3" L (57)

Download Geometry

Need help with the measurement?

Need some help with the calculation? You can always visit a Gazelle bike shop in your area to have your frame size determined.
