I got this for commuting, having no desire to get a car, and now I'm sure I'll never need one. This is, by far, the most comfortable bike I've ever ridden. And it just *flies* up hills.
Daniel SchwartzSeptember 3, 2023
Certifications
Intertek ETL Listed
Specifications
Battery
Charger
Bosch Standard Charger, 2A
Battery Position
integrated in the frame
Display
Display
Bosch Purion 200
Display Removable
false
Display Type
LCD colour
Support Levels
4
Support Values
Eco, Tour, Auto, Turbo
Ebike Walk Assist
true
Motor
Ebike Max Speed
20 mph
Engine Max Torque (Nm)
75
Motor
Performance Line
Ebike Engine Position
Mid
Ebike System Brand
Bosch Smart System
Battery and Range
540 Wh
Capacity
15 Ah
Battery Brand
Bosch
Ebike Battery Charging Time with 2A Charger
7 h 42 m
Battery Model
Intube
Eco
94 mi
Tour
56 mi
Auto
44 mi
Turbo
38 mi
Voltage
36V
540 Wh
Capacity
15 Ah
Battery Brand
Bosch
Ebike Battery Charging Time with 2A Charger
7 h 42 m
Battery Model
Intube
Eco
94 mi
Tour
56 mi
Auto
44 mi
Turbo
38 mi
Voltage
36V
Fork
Fork Lockout
false
Fork Material
aluminum
Fork Suspension
Telescope, spiral spring
Fork Travel
50 mm
Frame
Frame Description
Stable, lightweight hydro-formed aluminum frame with 68.5° headset angle and 69.5° seat tube angle for relaxed and comfortable riding. This is a low-step and spacious frame, single tube and lovely integrated cables
Frame Material
aluminum
Frame hape
Low-Step
Frame Size CM
M(53), S(46), L(57)
Weight (lbs)
59.5 lbs excl. battery
Color
ivory white matte, anthracite grey gloss
Model
Arroyo
Segment
Electric bicycles, City bikes
Sitting Position
Upright
Handlebar
Handlebar Description
aluminum, comfort curved model
Cockpit Handlebar Grip Brand
Gazelle Aero Leather, luxury leather handlebar grips for a sophisticated feel and extra comfort
Stem Adjustable
true
Saddle
Saddle
Selle Royal Lena Gel
Seatpost Suspension
true
Front Light
Front Light Energy Source
battery
Front Light
Gazelle Fendervision
Rear Light
Rear Light Energy Source
battery
Rear Light
Spanninga Pimento
Carrier
Front Carrier
false
Rear Carrier
true
Rear Carrier Description
aluminum MIK HD system carrier
Carrier MIK Profile
true
Lock
Lock
Axa
Lock Description
ring lock with an option for a plug-in cable to attach your bike to a fixed object for extra protection against theft
ART Classification
ART**
Other
Kickstand
Ursus Mooi
Kickstand Type
drop-down rear stand
Battery Warranty
2 year's warranty
Display Warranty
2 year's warranty
Fork Warranty
5 year's warranty
Frame Warranty
10 year's warranty
Motor Warranty
2 year's warranty
Paint Warranty
5 year's warranty
Other Parts Warranty
2 year's warranty
Brakes
Front Brake
Tektro HD-T280
Front Brake
180 mm
Front Brake Lever
Tektro HD-T280
Front Brake Piston Number
2
Front Brake Type
hydraulic disc brake
Rear Brake
Tektro HD-T280
Rear Brake
160 mm
Rear Brake Lever
Tektro HD-T280
Rear Brake Piston Number
2
Rear Brake Type
hydraulic disc brake/
Drivetrain
Drivetrain
Gates CDC
Drivetrain
belt
Front Sprocket
46, Gates CDC
Rear Sprocket
34, Gates CDC
Gears
Rear derailleur
Shimano Nexus 5
Gear Type
Hub
Number of gears
5
Tires
Wheels Tire Front ETRTO
50-622
ETRTO Tire Rear
50-622
Front Tire
Schwalbe Energizer Active Plus
Rear Tire
Schwalbe Energizer Active Plus
Wheels
Front hub
Shimano
Front rim
Ryde ZAC 421, double-walled aluminum for extra strong and efficient cycling performance
Front Wheel Size
28"
Rear Hub
Shimano Nexus 5
Rear Rim
Ryde ZAC 421, double-walled aluminum for extra strong and efficient cycling performance
)
