Knowledge Base eBikes
Electric Bicycle Battery & Range
Gazelle Electric Bike Batteries
Enjoying the ride on your Gazelle electric bike should never be limited by the battery. That’s why we spec all Gazelle bikes with the highest capacity lithium ion batteries available from both Bosch and Shimano. Depending on the model, our electric bike batteries are either mounted on the rear rack or built into the frame. Select models are also dual battery compatible.
The various batteries deliver different amounts of energy, causing differences in the range. Scroll down for range information by battery types. For Bosch battery systems, you can use the Bosch Range Assistant tool to get highly specific and customized information based on inputting your unique riding details.
Bosch Active Line Battery Table
Gazelles with this 400 Wh Bosch electric bicycle battery boast a range of up to 65 miles.
Bosch Active Line Motor System | |
Watt hour rating | 400 Wh |
Ampere rating | 11,1 Ah |
Max. Eco range | 65 miles |
Max. Tour range | 40 miles |
Max. Sport range | 30 miles |
Max. Turbo range | 25 miles |
Bosch Active Line Plus Battery Table
Gazelles with this 500 Wh Bosch electric bicycle battery boast a range of up to 90 miles.
Bosch Active Line Plus Motor System | |||
Watt hour rating | 400 Wh | 500 Wh | 540 Wh |
Ampere rating | 11,1 Ah | 13,4 Ah | 15,1 Ah |
Max. Eco range | 60 miles | 90 miles | 95 miles |
Max. Tour range | 35 miles | 55 miles | 60 miles |
Max. Sport range | 25 miles | 43 miles | 45 miles |
Max. Turbo range | 20 miles | 36 miles | 40 miles |
Bosch Performance Line Battery Table
Gazelles with this 500 Wh Bosch electric bicycle battery boast a range of up to 100 miles. Or 625 Wh has up to 122 miles.
Bosch Performance Line Motor System | ||
Watt hour rating | 500 Wh | 625 Wh |
Ampere rating | 13,4 Ah | 16,7 Ah |
Max. Eco range | 100 miles | 122 miles |
Max. Tour range | 55 miles | 83 miles |
Max. Sport range | 43 miles | 70 miles |
Max. Turbo range | 40 miles | 64 miles |
Bosch Perfomance Line Speed Battery Table
Gazelles with this 500 Wh Bosch electric bicycle battery boast a range of up to 75 miles. 750 Wh has up to 100 miles.
Bosch Performance Line Speed Motor System | ||
Watt hour rating | 500 Wh | 750Wh |
Ampere rating | 13,4 Ah | 20,1 Ah |
Max. Eco range | 75 miles | 100 miles |
Max. Tour range | 50 miles | 73 miles |
Max. Sport range | 40 miles | 62 miles |
Max. Turbo range | 35 miles | 58 miles |
Shimano STEPS Battery Table
Gazelle bikes with the 504 Wh STEPs electric bicycle battery boast a range of up to 100 miles.
Shimano STEPS Motor System | |
Watt hour rating | 504 Wh |
Ampere rating | 13,8 Ah |
Max. Eco range | 100 miles |
Max. Normal range | 70 miles |
Max. High range | 40 miles |
*The range for your bicycle is dependent upon several factors: tire pressure, rider weight, assist level, terrain, headwinds, cargo, and the age of the battery. It is normal for the charging capacity to reduce slightly over time. Although there is no need to always charge your battery fully, we do recommend bringing your battery up to a full charge once every 3 months.
